Channels: 4 + mic Audio Interface: 4-in/4-out, 24-bit/96kHz via USB
MIDI Control: Complete MIDI control
Effects: 2 x effects engines, each with delays, reverbs, modulators, resonators, and damage effects
Analog Inputs: 2 x stereo RCA line, 2 x stereo RCA line/phono, 1 x XLR mic
Analog Outputs: 2 x XLR, 2 x 1/4", 1 x stereo RCA
Digital Inputs: 2 x stereo S/PDIF (coaxial)
Digital Outputs: 1 x stereo S/PDIF (coaxial)
Headphones: 1 x 1/4"
MIDI I/O: via
USB USB: 1 x Type B
Other I/O: 1 x X:LINK (RJ45), 4 x Deck Start (1/8")
Faders: 4 x Long Throw
Crossfader: Adjustable
EQs: Configurable as asymmetric 3-band (+6/-25dB) with kills, Isolator (+6dB/off), or Highpass/Lowpass filters
Rackmountable: Yes (requires optional X:DB4-RK19 rack ear kit)
Height: 3.5" Width: 12.6" (19" with rack ears fitted) Depth: 14" Weight: 11 lbs.
